Understanding Active Directory: The Technology Behind Enterprise AI Security - Part 1: Understanding the Basic Concepts

Understanding Active Directory: The Technology Behind Enterprise AI Security - Part 1: Understanding the Basic Concepts

Understanding the account infrastructure behind AI systems

When planning an internal AI system, you may need to connect questions such as who can use it and which information they can access to the organization’s account management. Active Directory is one of the foundations worth understanding.

This series focuses on Active Directory Domain Services (AD DS) in Windows Server, covering accounts, authentication, permissions, and operations. Before considering how to connect an AI application, let’s understand what the underlying infrastructure does.

Part 1 covers the information AD DS manages, its relationship with DNS, and the differences between Kerberos, NTLM, and Basic authentication. The comics use fictional conversations to explain concepts; primary sources for the technical explanations appear at the end of each section.

Sources

Series Outline


1.1 Active Directory fundamentals

1.1.1 The role and functions of AD

Verifying identity and granting access are different jobs. Dialogue follows below.
Verifying identity and granting access are different jobs.
  • Developer“If I can sign in to a work PC, can I open any shared folder?”
  • Trainer“Sign-in verifies who you are. That is authentication.”
  • Trainer“When you open a folder, the server checks your permissions. That is authorization.”
  • Developer“So checking who I am and what I may use are separate.”

AD is infrastructure for managing account information shared across an organization.

This series covers Active Directory Domain Services (AD DS) in Windows Server. It stores information about users, computers, groups, and other objects in a directory and makes it available within the organization.

Shared account information lets integrated systems work with the same users. However, having an account and being allowed to use a particular file are different things.

Separate identity verification from access permissions

Authentication verifies identity; authorization decides whether an operation is allowed.

For a shared folder, the file server checks access rights using the authenticated user and group memberships. Merely setting a department attribute to “Accounting” does not grant access to an accounting folder.

RoleWhat it checks in shared-folder access
AuthenticationWho the user is. Verify identity using a domain account.
AuthorizationWhether that user may perform an operation. Decide whether reading or writing is allowed by permissions assigned to users or groups.
A simplified view of roles when accessing a shared folder, not a network message sequence.Authentication verifies identityVerify the user through a domain accountAuthorization decides what is allowedThe file server evaluates access permissionsPerform permitted operationsIdentity verification alone does not grant all access
A simplified view of roles when accessing a shared folder, not a network message sequence.

Supporting SSO and centralized settings

Single sign-on (SSO) reduces repeated credential entry across integrated services.

With Windows Kerberos authentication, a client can obtain the tickets needed for services after logon and use them to demonstrate the user’s identity to supported services. Each service’s permission settings determine what the user may do.

Administrators can apply settings collected in Group Policy Objects (GPOs) to users and computers. GPO links and applicability conditions determine the targets, with processing at times such as startup, logon, and background refresh.

It is easier to understand AD when you distinguish account information, identity verification, access rights, and the application of settings.

Sources

1.1.2 Managing users, computers, and groups

Users, computers, and security groups have different roles. Dialogue follows below.
Users, computers, and security groups have different roles.
  • Developer“Once the user is registered, is the new PC ready too?”
  • Trainer“Users and computers are managed as separate accounts.”
  • Trainer“You can assign shared-folder permissions to security groups.”
  • Developer“People, devices, and groups for permissions each have a different role.”

Users, devices, and groups used to assign permissions are managed as distinct objects.

A user account identifies a user, while a computer account identifies a computer that joins the domain. Registering a user does not, by itself, join a device to the domain or complete its configuration.

ObjectMain role
UserManage an identity and its account information
ComputerManage the identity of a domain-joined computer
Security groupCollect accounts and other members for assigning permissions and user rights
Organizational unit (OU)Organize objects, delegate administration, and design Group Policy scope

Groups and OUs serve different purposes.

A security group can be used when assigning access to a shared folder. Moving an object into an OU or changing its department attribute does not automatically grant that folder’s permissions.

An OU structure need not copy the organization chart. Design it around who will administer the objects and which users or computers should receive particular settings.

Sources

1.1.3 The role of domain controllers

Domain controllers share changes through replication. Dialogue follows below.
Domain controllers share changes through replication.
  • Developer“Which server keeps the account information?”
  • Trainer“Domain controllers hold the information and provide services such as authentication.”
  • Trainer“With multiple controllers, changes are shared by replication. That can take time.”
  • Developer“So having several servers is not enough. We also check that replication is working.”

A domain controller (DC) stores directory information and provides services such as authentication.

AD DS replicates the relevant directory information between DCs. Changes take time to reach other DCs, so the information returned can differ depending on the DC while replication is in progress.

Deploying multiple DCs is part of preparing for a server outage. Availability also depends on functioning replication, name resolution, and network paths, not simply the number of servers.

A conceptual view of sharing changes between DCs, not a diagram of replication connections.The DC that accepts a changeStores the updated informationReplication carries the changeReplication to relevant DCs takes timeA DC holding the relevant dataApplies the changes it receives
A conceptual view of sharing changes between DCs, not a diagram of replication connections.

Do not assume that every DC always holds all data for the entire organization. Check which information is replicated where, and continue monitoring replication after adding a DC.

Sources

1.2 Active Directory and DNS

1.2.1 Why AD needs DNS

Finding a server comes before authenticating to it. Dialogue follows below.
Finding a server comes before authenticating to it.
  • Developer“My password is correct, but I cannot connect to the domain.”
  • Trainer“First, let us check whether the PC can find a server to connect to.”
  • Trainer“The PC uses service information registered in DNS to find a domain controller.”
  • Developer“Finding a server and verifying my identity are separate steps.”

Before authentication can begin, the client needs to find a server to contact.

DNS (Domain Name System) provides information about hosts and services by name. Windows DC Locator uses records such as SRV records registered in DNS to find candidate DCs.

After finding candidates, it contacts DCs to check their responses and capabilities. DNS does not verify a user’s password; server discovery and identity verification are separate stages.

  1. 1The PC queries DNS for information about the DC it needs.
  2. 2It contacts candidates found through DNS to locate an available DC.
  3. 3It performs the required operations, such as logon, with the selected DC.

Site-specific records also help locate an appropriate DC. Understand AD site configuration together with DC Locator, rather than assuming that DNS automatically identifies the nearest office from an IP address alone.

Sources

1.2.2 How AD-integrated DNS works

AD-integrated DNS stores DNS zone data in AD DS and replicates it through AD.

A DNS zone is a unit for managing a portion of the DNS namespace. An AD-integrated zone shares its data using the AD replication mechanism.

DNS servers on writable DCs holding the AD-integrated zone can accept updates to it. Configuration determines the replication scope; a zone is not unconditionally copied to every DC in the forest.

MechanismWhat it does
AD-integrated zoneDetermines where DNS data is stored and how it is replicated
Dynamic updateAllows clients or DHCP servers to request record additions and changes
Secure dynamic updateControls updates using the identity and permissions of the updating principal

AD integration and dynamic update do not mean the same thing. Creating a user account also does not automatically create a DNS record for that user.

Sources

1.2.3 The role of SRV records

An SRV record identifies where a service is provided. Dialogue follows below.
An SRV record identifies where a service is provided.
  • Developer“Is registering the server IP address in DNS enough?”
  • Trainer“SRV records also identify the host and port that provide a service.”
  • Trainer“They can include priority and weight. Weight is not a measurement of current load.”
  • Developer“So we can find not only an address, but also where a service is provided.”

An SRV record identifies the host and port providing a service.

A and AAAA records resolve host addresses, whereas SRV records locate services. DC Locator uses SRV records for services such as LDAP.

LDAP is a protocol for accessing a directory. In this context, LDAP is one of the services involved in DC discovery, rather than simply an “authentication service.”

The following illustrative DNS zone-file entry uses the reserved example domain example.com. These are not the configuration values of an actual organization.

_ldap._tcp.example.com. 600 IN SRV 0 100 389 dc01.example.com.
FieldValue and meaning in this example
Name_ldap._tcp.example.com. identifies the LDAP service over TCP for the domain
TTL and class600 is the cache lifetime in seconds; IN denotes the Internet class
Priority0. Lower numbers are preferred
Weight100. A relative weight for selecting among records with the same priority
Port and target389 and dc01.example.com. identify the service port and hostname

Weight is not a measurement of current CPU utilization or connection count. Distinguish SRV selection rules from the application’s discovery and connection behavior.

Sources

1.2.4 Dynamic DNS updates

Dynamic updates allow changes such as new addresses to be reflected in DNS.

Windows DNS clients attempt record updates at events such as startup or address changes. In a DHCP environment, client and DHCP server settings determine which party updates A and PTR records.

  1. 1Relevant information changes, such as the device name or address.
  2. 2The DNS client or DHCP server requests an update according to its configuration.
  3. 3The DNS server checks the update conditions and permissions, then updates authorized records.

An authenticated device is not allowed to overwrite any name it chooses.

Secure dynamic updates involve access control on records and other relevant objects as well as authentication. Connecting to a VPN does not guarantee automatic registration; check adapter and name-registration settings.

When investigating name-resolution problems, compare the current address, DNS records, and the principal making updates. Check the actual update configuration, including how stale records are handled.

Sources

1.3 Authentication protocols

1.3.1 Kerberos authentication

A Kerberos ticket is not an all-access pass. Dialogue follows below.
A Kerberos ticket is not an all-access pass.
  • Developer“Does the first ticket let me use every service?”
  • Trainer“You use the initial TGT to obtain a service ticket for the destination.”
  • Trainer“The service verifies your identity with the ticket, then checks permissions for the operation.”
  • Developer“A ticket is not an all-access pass to everything.”

Kerberos uses tickets to demonstrate a client’s identity to a service.

In a Windows domain, the Key Distribution Center (KDC) on a DC issues tickets. A client obtains a Ticket Granting Ticket (TGT) and can use it to request a ticket for the destination service.

A conceptual view of using a service with Kerberos, separating ticket acquisition from permission checks.Obtain a TGTUse it to request service ticketsObtain a service ticketRequest a ticket for the target service from the KDCPresent the ticket to the serviceThe service verifies the identityCheck permissions at the servicePerform the operations that are allowed
A conceptual view of using a service with Kerberos, separating ticket acquisition from permission checks.

Tickets reduce the need for users to enter a password each time they connect to a supported service. A service can verify the ticket; it does not necessarily ask a DC to verify identity for every connection.

Having a ticket does not grant access to every function of the service. The file server or application decides which operations the user or their groups are permitted to perform.

Sources

1.3.2 NTLM authentication

NTLM is an authentication protocol based on challenge and response.

The client responds to the server’s challenge using information derived from the password. The NTLM authentication exchange does not send the password itself in plain form.

For a domain account, the server can pass validation to a DC. Local accounts are validated against local information, so it is inaccurate to say NTLM always contacts a DC for every access.

QuestionWhat to examine
Why NTLM is being usedApplication support, the way the destination is specified, and authentication settings
Migrating to KerberosNTLM dependencies and support in each application
Restricting NTLMAudit existing usage, then test the impact of restrictions

When you find NTLM in use, investigate why it was selected for that connection. Do not disable it across the board without checking the effects on existing services.

Sources

1.3.3 Basic authentication

Base64 encoding is not encryption. Dialogue follows below.
Base64 encoding is not encryption.
  • Developer“The Basic authentication string looks unfamiliar. Is it encrypted?”
  • Trainer“Base64 is encoding. It can be decoded back into the username and password.”
  • Trainer“HTTPS is needed to protect the connection. Check it separately from the authentication method.”
  • Developer“So I check connection protection and authentication settings, not how the string looks.”

Basic is an HTTP authentication scheme, and its Base64 encoding is not encryption.

The client combines a username and password, Base64-encodes them, and sends the result as credentials. Anyone who obtains the encoded value can reverse the encoding, so Basic itself does not conceal the communication.

MechanismRole
Basic authenticationCarries credentials in an HTTP request
Base64A reversible encoding that represents data as another string
HTTPSProtects the communication channel using TLS

If Basic authentication is used for sensitive information, protection such as HTTPS is necessary. HTTPS protects the channel; it does not replace proper credential handling at the receiving system or access-control design.

Basic is not a final fallback that AD automatically selects for external connections. Check the client and server settings for the authentication schemes that the HTTP service provides.

Sources

1.3.4 Choosing authentication methods

Assess authentication methods together with application support and connection conditions.

Windows Negotiate selects Kerberos or NTLM. There is no universal automatic sequence that falls back from Kerberos to NTLM and then to Basic for every connection.

ScenarioHow to assess it
A connection supporting Windows integrated authenticationCheck whether Kerberos can be used and determine which method was actually selected
A host specified by IP addressWindows does not attempt Kerberos by default. Special configuration can provide exceptions; normally, configure DNS names and service identity information appropriately
A connection through a VPNCheck DNS, reachability, and authentication settings after connecting. The VPN alone does not guarantee a particular method
A connection to an HTTP serviceCheck the schemes offered by the service and channel protection. Being internal or external alone does not determine the method

An order for investigating authentication problems

When a connection fails, separate discovery, communication, authentication, and permissions instead of assuming the password is wrong. The following sequence organizes the roles covered in this chapter.

  1. 1Identify the service and the name used to connect to it.
  2. 2Check DNS discovery and connectivity to the required endpoints.
  3. 3Check the methods offered by the application and the method recorded in logs.
  4. 4If Kerberos is expected, check connection conditions and settings such as the service principal name (SPN).
  5. 5If identity verification succeeds but access is denied, inspect permissions.

Distinguishing “the destination cannot be found,” “identity verification failed,” and “the operation is not permitted” is a starting point for understanding systems that use AD. The next installment explores structures such as domains and forests.

Sources
